Yeni D-Max artık daha güçlü ve daha teknolojik.
Isuzu D-Max, sekiz yılın ardından ilk defa tamamen yenilendi. Pick up modelinin tanıtımı, üretiminin de yapılacağı Tayland’da gerçekleştirildi. Tasarım anlamında mevcut modele göre daha agresif bir görüntüye kavuşan D-Max daha büyük bir ızgara, daha ince LED farlar ve daha keskin bir bölümle geldi.
Yan profilden daha kısa ve iri görünen 2020 D-Max, arka bölümde ise eskisinden daha şık görünmesini sağlayan LED farlara kavuştu. Arkaya monte edilmiş basamaklı tampon, pick up modelinin güçlü görünümüne katkıda bulunuyor.
Galeri: 2020 Isuzu D-Max
Üçüncü jenerasyon D-Max’in kabini daha modern ve teknolojik hale getirildi. Apple CarPlay ve Android Auto destekli 9 inçlik bilgi eğlence sistemi, piyano biçimli tuşlara ev sahipliği yapan V şekilli merkez konsol, çok fonksiyonlu direksiyon simidi ve gösterge panelinde yer alan 4.2 inçlik ekranın yanı sıra aracın koltukları da yenilendi.
2020 D-Max, pazara göre değişmekle birlikte iki tane güncellenmiş dört silindirli turbodizel motorla sunulacak. Standart 1.9 litrelik ünite 150 bg güç ve 350 Nm tork üretirken, 3.0 litrelik diğer seçenek 190 beygir güç ve 450 Nm tork sağlayacak. Her iki motor da standart olarak altı ileri manuel şanzımanla birlikte çalışacak, ancak 1.9 litrelik ünite opsiyonel olarak yeni geliştirilen otomatik şanzımanla tercih edilebilecek.
Dört tekerlekten çekişli D-Max modelleri aynı zamanda, arazi kabiliyetini artıran ve iki tekerlekli ve dört tekerlekli sürüş arasında geçiş yapmak için gereken süreyi azaltan bir elektromanyetik arka diferansiyel kilidiyle gelecek.
Regular Cab, Space Cab ve Crew Cab gövde stilleri ile sunulacak yeni D-Max, Tayland’da birkaç gün içinde piyasaya sürülecek. Aracın Türkiye gibi diğer pazarlarda satışa çıkması ise 2020 yılını bulacak.
Isuzu pick-up D-MAX has undergone a full model change in the first time in 8 years
Isuzu Motors Limited (headquartered in Shinagawa, Tokyo; Masanori Katayama, President and Representative Director; hereinafter "Isuzu") full-model-changed a one-ton pick-up truck Isuzu D-MAX (hereinafter D-MAX) and will start sales from October 19.
The pick-up truck is well designed not only as a passenger car for personal use but also as a vehicle of station-wagon type for business use, and widely popular especially in Thailand. D-MAX has remained the top-ranking brand in Thailand, and the awards it has received include the 2019 Most Popular Pick-up Truck, Best Fuel Saving Pick-up Truck, Best Life Style Pick-up Truck, etc.
In conjunction with the full model change, a development concept of Efficient and Robust was formulated to pursue a vehicle that delivers higher fuel efficiency and safety while responding to various usage conditions and purposes. Moreover, its exterior design is so distinctively new that it's over and above the conventional pick-up trucks.
Since Isuzu Motors Co., (Thailand) Ltd. (IMCT), the mother plant of pick-up trucks, began a localized production in 1974, it has rolled out over 4 million vehicles turning itself into a worldwide pick-up truck provider serving not only Thailand but more than 100 countries globally.
Strengthen LCV business is part of the key challenges Isuzu has made in the mid-term business plan published in May 2018. The main aim of the model change this time is to fulfill various needs of customers by offering a wide range of variation. Simultaneously, Isuzu will leverage its core business operations developed during the previous business plan years to increase sales and take a lead in the LCV market.
Below are the main features of brand new D-MAX
- ·Core structure
- Lean, rational assembly structure and extensive use of high-tensile steel plates achieved light but firm vehicle body. To live up to popularity of D-MAX in Thailand where rain falls steadily, its anti-corrosion ability is greatly improved, and it is capable of driving through the river bed for 800 mm. Moreover, it's designed in such a way that its electrical architecture flexibly accommodates evolution in security and connected technologies.
- ·Fuel economy
- The new D-MAX offers market-leading low fuel consumption and CO2 emissions.
- D-MAX has actively adopted advanced safety features that meet market needs.
Its driving stability and comfort are also enhanced together with its braking performance.
- ·Convenience and features
- In addition to enriching the contents of D-MAX's infotainment system, various features are added to increase convenience. The technology and quality of interior components are also upgraded, and the interior noise is significantly reduced.
- Developed under the concept of Beyond the Pick-up Truck, the D-MAX's design is so distinctively new that it's over and above the conventional pick-up trucks transforming it into a whole new pick-up so as to reflect the keywords: Bold, Emotional and Smart.
- Chunky exterior profile with a wedge body shape constitutes more powerful, swishing silhouette than ever before. In the headlamps, bi-led projectors combined with stylish signature lamps are installed giving an eager, intense look. In the tail lamps, dual LED edge lights are employed. These new light designs generate a unique, stylish appearance both front and rear.
A neatly integrated step bumper is mounted on the rear, giving an all-new, sophisticated look.
- A 9-inch display is mounted in the center of a horizontally-flowing instrumental panel. Strikingly contrasting design is created by sharp and rich surface textures. The new D-MAX's interior is designed to generate a first-class appearance with the introduction of a floor console, which is now taller and wider. Also, it is designed to enfold the driver and passenger as if they were in a cockpit of an airplane.
Detailed attention is paid to its interior components having embossed and texturized surfaces to achieve a high-end, sporty look.
For the workhorse applications, simply and practically designed instrumental panel and door trim can be opted.
- 4JJ3 engine is newly developed based on the reliable and well-received 4JJ1 diesel engine (3L displacement). The combined effects of 250 MPa high injection pressure, electronically-controlled VSG turbocharger, heat-insulating coating on the piston, double-scissors gear, etc. has yielded the engine featuring high power, low fuel consumption and low noise.
The engine performance of RZ4E diesel engine (1.9L displacement) is also revamped by optimizing its gear ratio and control systems.
- Pull-ring shift lever is chosen for the manual transmission to make it easier for the driver to reverse the vehicle, and drive feel is better and more engaging.
With regard to the automatic transmission developed for RZ4E diesel engine, a downsized torque converter and lockup clutch integrated with a wide-angle damper provide improvements in fuel consumption and response.
A single propeller shaft made of aluminum is now incorporated in the 4x4 vehicle to achieve a significant weight reduction. The new D-MAX is also mounted with an electromagnetic rear differential lock.
With an enhanced transfer of power to the wheels, it now takes shorter time to switch between 2-wheel and 4-wheel drive as well as between high and low.
- The D-MAX's high-ride model employs high-mounted front suspensions with upper links to boost driving stability and conform. The rear suspension, on the other hand, features a wider rear tread and reduced mounting angle for the shock absorber, whereby a better driving stability is achieved.
- Steering/handling has improved as a result of increasing the tire turning angle and reducing the minimum turning radius.
With regard to the new D-MAX's high-ride model, not only its steering unit has been revised to reduce the effort required for steering, but also a change in the gear ratio has improved its steering performance.
It comes with a tilt/telescopic steering column to accommodate drivers of all sizes.
- An increase in the D-MAX's brake rotor size and a change in the servo ratio enabled to improve its braking performance, braking feel and noise/vibration levels.
- As a result of expanding the cross section, optimizing the locations of cross-members and improving impact absorption, greater frame rigidity and safety are ensured while achieving lightweight. Moreover, a shear mount is used in the place of the body mount in order to improve driving stability and lower noise/vibration levels.
- ·Vehicle body
- In addition to developing a lean, rational assembly structure for the new D-MAX, the use of 980 MPa high-tensile steel plates and other things have made it possible to achieve stronger body rigidity while keeping it lightweight. The application of higher than 390 MPa high-tensile steel plates has increased from 30% to 46%.
Not only its body rigidity is up by 20%, but its rooftop is also reinforced. Through the improvements made on the package design, each cab type now features an extended loading platform.
- ·Interior finishing
- Low-rebound MDI polyurethane is selected for front seat cushions to reduce fatigue that long-distance drivers have to endure. Further, an addition of eight-way power seat helps to support physical condition particularly to the thigh.
Front seat developed for the new D-MAX to prevent whiplash injuries comes standard to all models.
In addition, the safety has been taken into consideration, such as wearing a seat belt reminder to encourage belt wearing.
The design of a rear seat in the crew cab is optimized to improve ride comfort. To allow for easy getting on/off, an opening of the B-pillar is shifted forward and assist grip is added.
- ·Electrical component
- The EE architecture is configured using the central gateway in order to pave the way to the new CASE era.
Technologies designed to optimize convenience & comfort are extensively employed such as keyless entry, infotainment, lights, wipers, etc.
Keyless entry Remote engine start, Welcome light, Walk-away lock Infotainment 7/9" WXGA anti-static touch panel , Compatible to Apple Carplay/Android Auto, Voice recognition, Link to 4.2" MID, etc. Light Automatic headlight system, Emergency stop signal, Follow me home lights, etc. Wiper Reversing motor wipers (Wet wipers), Automatic wipers Other Dual zone A/C unit, Park distance control (Front and rear sonars)
- D-MAX's front hub bearing is now maintenance free as it is part of unit bearing. Maintenance schedules for other items are extended, and the maintenance frequency and costs are greatly reduced.
Snapshot of specification
- ·Vehicle Model : Crew Cab Hi-Ride 4×2 MT designed for Thailand
Vehicle model Crew Cab Hi-Ride 4×2 Total length including rear bumper(mm) 5,265 Total width(mm) 1,870 Total height including roof rails(mm) 1,790 Wheelbase(mm) 3,125 Tread(front/rear)(mm) 1,570 Minimum turning radius(m) 6.1 Tire 265/60R18 Engine
Engine displacement(cc) 2,999 Power(kW/rpm) 140/3,600 Torque(Nm/rpm) 450/1,600-2,600 Transmission MVL 6MT Vehicle curb mass(kg) 1,890 CO2 emissions(g) 181
